Engine Room® LVL8 Power Supply | Fender

Pedals need clean isolated power and Fender’s Engine Room® LVL8 Power Supply is capable of the task.

Featuring eight ground isolated power outlets, (6) are capable of delivering 9Vdc at 500mA while (2) additional outlets provide switchable voltage (9v/12v/18v) via 3-way toggle or slide switch.

$329.00

Availability: 1 in stock

SKU: 0230103008 Categories: , Brand:

Perfect for performance or studio players and can be daisy-chained with our LVL12 for players looking for more tonal variety.

The Engine Room® Power Supply is designed by our in-house team of experts in Southern California. The chassis is crafted from lightweight, durable anodized aluminum, and its sleek, low-profile appearance is engineered to accommodate most pedalboards. Also features a 2-color LED indicator for each output, green indicating current consumption. Road-tested and ready for live or studio use, Fender’s Engine Room® Power Supply is built to power your performance.

Features

  • 8 ground isolated outputs – 6 outlets fixed 9Vdc at 500mA and 2 outlets with switchable voltage (9v/12v/18v)
  • Global mains input voltage (100-240Vac) 50/60Hz for use anywhere in the world
  • Standard IEC mains voltage connector
  • Dimensions: Width: 9.6” (244mm), Height: 1.65” (42mm), Depth: 3.59” (91.3mm)
  • 5V USB-A and USBC output for charging smart devices
  • Cable kit included:
    • 4 x 2.1mm barrel connector 24” (60cm) length
    • 2 x 2.1mm barrel connector 18” (45cm) length
    • 2 x 2.1mm barrel connector 12” (30cm) length
    • 1 x 2.5mm to 2.1mm barrel
    • 1 x 2.5mm to 2.1mm barrel reverse polarity
    • 1 x 3.5mm TS to 2.1mm barrel
    • 1 x 9V Battery clip to 2.1mm barrel
Weight 1.545 kg
Dimensions 33 × 22 × 5 cm
