CLEARLY LABELED FUNCTIONS TO EASILY SET TONES & OTHER BASIC SETTINGS
15 “Advanced tones” painstakingly crafted with the full potential of the AiX sound source, including masterpieces of grand pianos, keys, winds and strings for unique musical expression.
IN THE BEDROOM OR A GRAND HALL?
Volume-Sync EQ intelligently optimising the EQ setting as the volume changes, and Surround expanding the sound field, secures punch and width at any volume.
COMPATIBILITY WITH BLUETOOTH MIDI & AUDIO ADAPTOR
The CT-S500 is compatible with the WU-BT10 (comes in box). Plug in and play on the Casio Music Space app. Free to download on the Google Play and Apple App Store.
Number of Keys:
- 61
Touch Response:
- 3 sensitivity levels
Sound Source:
- AiX
Maximum Polyphony:
- 64
Number of Tones:
- 800
Songs:
Part Off: Left Hand, Right Hand, Both Hands
Recorder:
• MIDI Recorder
• 6 tracks, 5 songs
• Approximately 40,000 notes for each song
Pedal:
• PEDAL 1: Standard jack
• PEDAL 2 / EXPRESSION: Standard jack
Speaker:
13cm x 6cm x 2
Amplifiers:
2.5W + 2.5W
Power Supply:
• AC Adaptor: AD-A12150LW (DC 12V)
• Batteries: AA-size alkaline batteries x 6 or AA-size rechargeable nickel metal hydride batteries* x 6
• Battery Life: Approximately 3 hours continuous operation
• Actual continuous operation time may be shorter due to battery type, performance type, and usage environment.
*Measured values while using eneloop batteries. eneloop is a trademark of Panasonic group.
Power Consumption:
- 7.5W
Dimensions:
930 x 258 x 91 mm (w/o music stand)
Included Accessories:
• Music Stand
• AC Adaptor AD-A12150LW
• Wireless MIDI & Audio Adaptor WU-BT10
• Strap Lock
Number of Rhythms / Patterns:
• 243
• User Rhythms: 50
Weight:
4.7kg (w/o batteries)
Effects:
• Reverb: 24 (+Preset for each tone)
• Chorus: 12 (+ Preset for each tone)
• Delay: 15 (+ Preset for each tone)
• DSP Effect: 100 (+ Preset for each tone)
• Master EQ: 10 (+ User: 1)
• Surround
Layer/Split:
- Yes
- Layer: 3 (Upper1/2, Lower1)
Octave Shift:
- -3 octaves ~ 0 ~ +3 octaves
Transpose:
- -12 semitones ~ 0 ~ +12 semitones
Tuning Control:
- A4 = 415.5 Hz ~ 440.0 Hz ~ 465.9 Hz
Scales:
Equal temperament + 16 variations
Arpeggiator:
- 150
Registration:
- 64 setups (4 sets x 16 banks)
Metronome:
• Beat Bell: Off, 1 to 9 (beats)
• Tempo Range: 20 to 255
• Tap Tempo: Yes
LCD:
- Full-dot LCD with backlight
Pitch Bend Wheel:
- Yes
Other Features:
• One Touch Presets: 243
• Automatic Accompaniment
• Dial
• Volume Sync EQ
• Sampling Function
• Input Method: Audio In / Media (WAV)
• Sampling Type / Time: Sampling Melody × 1 / Approx. 10 sec., Sampling Drum Set ×1 / Approx. 3 sec.
• Format: 44.1kHz, 16 bit, Stereo
• Loop Functionality
